    RDT crossbow project

    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty RDT crossbow project

    Post by jrdallmann Tue Oct 28, 2014 6:10 pm

    First topic message reminder :

    Hello folks!
    First of all, I'm from Brazil, so sorry my bad English. I'm planning to build my first crossbow on next vacation, which begins within about a month. I've been doing a lot of research about it for the last few months. Since I own a car shop, I got everything I need to build my crossbow.
    I'm inspiring myself on patandjali's rdt model. Today I started to search for components for my crossbow. I found a spring leaf from an old Willys which will be my prod and removed the valves and the valve guides from a VW engine head to use as axle and sleeve for the cams.

    RDT crossbow project - Page 2 Img_2011

    RDT crossbow project - Page 2 Img_2010
    The leaf is 40" long

    It's not a project I wanna do in a hurry, so I'll take my time. I'm open for suggestions.
    ali.j
    ali.j
    Tinkerer

    If there is a will, there is a way.


    TinkererIf there is a will, there  is a way.


    Posts : 76
    Join date : 2013-10-30
    Age : 30
    Location : iran- shiraz

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by ali.j Fri Nov 21, 2014 5:47 am

    today...

    RDT crossbow project - Page 2 21_14141657484165241

    RDT crossbow project - Page 2 21_14141657484187882

    RDT crossbow project - Page 2 21_14141657484200993

    RDT crossbow project - Page 2 21_14141657521182411

    RDT crossbow project - Page 2 21_14141657521196692
    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by jrdallmann Mon Dec 01, 2014 4:04 pm

    Hi guys. My vacation is coming soon, so I'm preparing everything to start working on my project. I already have almost everything I need. But, today, while working at my garage, I've thought about something.. what if instead of using an aluminum plate and working on it to build the cams, I use a pulley like the one below? I'd just have to work the "teeth" off and cut it to make the "entrance" for the string. what do you guys think?

    RDT crossbow project - Page 2 Polia-original-do-comando-vw-motor-ap-16-18-20-gol-parat-14402-MLB233374678_7914-O
    ali.j
    ali.j
    Tinkerer

    If there is a will, there is a way.


    TinkererIf there is a will, there  is a way.


    Posts : 76
    Join date : 2013-10-30
    Age : 30
    Location : iran- shiraz

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by ali.j Tue Dec 02, 2014 3:06 am

    no. Not working. You just have to like me, you use cams. meterial appropriate for made cam is al Alloys. no 5000 or 6000 or 7075.

    this clip It may help you in making.
    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by jrdallmann Tue Dec 02, 2014 7:50 am

    So the bowstring material kit i've bought just arrived yesterday. Since this will be my first time at making a bow string,I just want to clarify something.. In the picture below, the purple thread is dacron b 50 while the black one is serving material, right?

    RDT crossbow project - Page 2 Img_2010
    avatar
    Hermit
    Workshop Savvy

    Did you see my tool collection?


    Workshop SavvyDid you see my tool collection?


    Posts : 245
    Join date : 2013-09-10

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by Hermit Tue Dec 02, 2014 8:04 am

    Hi Jrd,Ali is right your gear wheel won't work.A gear wheel has to rotate eccentrically(in balance,like a car wheel).Acam rotates eccentrically(out of balance)it would be just about impossible to modify a gear wheel,you will have to make the cams yourself.
                                                                              Hermit.
    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by jrdallmann Tue Dec 02, 2014 2:55 pm

    I got it, haven't thought about that.. and what about the threads?
    avatar
    Hermit
    Workshop Savvy

    Did you see my tool collection?


    Workshop SavvyDid you see my tool collection?


    Posts : 245
    Join date : 2013-09-10

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by Hermit Thu Dec 04, 2014 9:17 am

    Looking at my spool of Dacron(It's grey in colour)I would say that the purple is the Dacron.
                                                            Hermit.
    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by jrdallmann Fri Dec 05, 2014 7:55 am

    ali.j why are there two holes in the center of your cams?
    ali.j
    ali.j
    Tinkerer

    If there is a will, there is a way.


    TinkererIf there is a will, there  is a way.


    Posts : 76
    Join date : 2013-10-30
    Age : 30
    Location : iran- shiraz

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by ali.j Sun Dec 07, 2014 12:10 pm

    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by jrdallmann Mon Dec 08, 2014 5:50 pm

    hey ali.j, can you tell me why there are 2 "center holes" in your cams?
    avatar
    Hermit
    Workshop Savvy

    Did you see my tool collection?


    Workshop SavvyDid you see my tool collection?


    Posts : 245
    Join date : 2013-09-10

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by Hermit Mon Dec 08, 2014 7:23 pm

    The central hole is for the cam pivot pin,the off centre hole is for the string anchor pin.
                           Hermit.
    hullutiedemies
    hullutiedemies
    Workshop Savvy

    Did you see my tool collection?


    Workshop SavvyDid you see my tool collection?


    Posts : 202
    Join date : 2012-07-03
    Location : Fennoscandia

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by hullutiedemies Tue Dec 09, 2014 2:28 am

    jrdallmann wrote:Hi guys. My vacation is coming soon, so I'm preparing everything to start working on my project. I already have almost everything I need. But, today, while working at my garage, I've thought about something.. what if instead of using an aluminum plate and working on it to build the cams, I use a pulley like the one below? I'd just have to work the "teeth" off and cut it to make the "entrance" for the string. what do you guys think?
    ..

    You could use pulleys. Here is one apparently succesful build for example :
    https://thearbalistguild.forumotion.com/t774-compound-project

    but it is going to be a bit different design.
    Force-draw curve will not be as efficient. But you can have longer power stroke since pulleys can turn multiple revolutions.
    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by jrdallmann Thu Dec 11, 2014 5:50 pm

    thanks for replying flinstone, but i'm not gonna use that kind of pulleys. Today I finally startes my crossbow. I decided to start from the most difficult part: cams. I mean, it's not that difficult, but toilsome. I wasn't able to finish them today because I only have time to work on my crossbow after job, and december is madness in my auto shop. However, is going well. I'm just a little bit worried because my aluminum plates are not exactly 8mm thick, they're little thinner, around 7mm, but  I guess that's no problem. Just to make sure, what is the thickness (approximately) of a crossbow string?
    avatar
    jrdallmann
    Fresh Blood

    Doesn't mean
    I'm new to crossbows


    Fresh Blood Doesn't meanI'm new to crossbows


    Posts : 17
    Join date : 2014-10-15

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by jrdallmann Tue Apr 21, 2015 12:43 pm

    hey guys, I had to put my crossbow project aside for a while due to college, work and stuff. Yet, I finished my first cam and would like you to take a look and tell me waht u think, I'm a little worried about the thickness..

    RDT crossbow project - Page 2 Img_2011

    RDT crossbow project - Page 2 Img_2010

    PS: not finished, i still have to drill it and do the second little cam
    ali.j
    ali.j
    Tinkerer

    If there is a will, there is a way.


    TinkererIf there is a will, there  is a way.


    Posts : 76
    Join date : 2013-10-30
    Age : 30
    Location : iran- shiraz

    RDT crossbow project - Page 2 Empty Re: RDT crossbow project

    Post by ali.j Thu Apr 23, 2015 3:31 pm

    Very Happy



    shooting test. 165 lbs/300 fps  Laughing






    RDT crossbow project - Page 2 16_151429217541082



    RDT crossbow project - Page 2 16_151429217541183



    RDT crossbow project - Page 2 16_151429217540981
